Roller chain specs

• Capacities: 9,000 to 25,000 lbs chain pull
• Speed: variable up to 200 ft/min
• Inclines: up to 35 degrees
• Drives: 5HP to 25HP, shaft mounted
• Safety: guarding, e-stops, pull cords
• Control: PLCs, HMIs, custom control systems
• Belt widths: 18" to 96"
• Roller chain belts: hinged, apron pan, z-pan, rubber, PVC, steel
• Chain pitch: 4", 6", 9" pitch. 12" pitch for select belts.
• Rollers: 3", 4", 5" diameters

Trough idler specs

• Frame material: ASTM A-36 steel framing
• Tubing: 3/16" wall rectangular tubing
• Sides: 1/4" formed pan steel plate
• Hardware: grade 8
• Finish: sandblasting and industrial grade powder coating, customizable color
• Width: standard widths from 48" to 120" and custom widths available
• Length: standard 10 to 30 ft lower horizontal lengths, custom lengths available
• Incline options: standard incline angles from 25-35 degrees, custom inclines available
• Drive shafts: precision machined cold rolled steel shafts
• Safety features: guarding, e-stops, dead man plates
• Bearings: heavy-duty B-type sealed bearings

• Controls: PLCs, HMIs, and custom control panels

Sort station specs

• Widths: 24" to 60"
• Speed: variable from 50 to 400 FPM
• Safety: pull cords, e-stops, dead man switches
• Control: PLCs, HMIs, and custom control panels
• Belts: PVC, plastic modular, urethane

Our conveyor manufacturing process

Our biomass organic waste recycling conveyors are designed and manufactured in the USA to CEMA standards and tolerances.

• Formed using heavy-duty steel plate, rectangular tubing, and structural channel
• Precision components such as cold-rolled steel shafts and flame-hardened sprockets
• All hardware is grade 8 for maximum strength
• Painted with industrial-grade powder coating for durability
• Designed for simple maintenance access and component serviceability
• Goodyear, Flexco belt options resistant to rips, tears, and impacts
• Baldor, Leeson, Toshiba TEFC motors selected for 24/7 operation
• All systems fabricated by certified welders for structural integrity
• ASTM A36 steel for fabrication per structural code
• Premium bearings sized for L10 life ratings, made in the USA
• Dodge, Nord, and SEW drives matched to application torque
• Extensively tested and inspected before shipment

• 3/16" and 1/4" thick structural steel frames to prevent flexing
• 25-35 pound rail track to withstand heavy loads

Our organic waste recycling conveyors deliver exceptional durability, strength, and longevity, year after year.

Biomass recycling profitability depends on the efficient collection, sorting, and transport of organic waste, which our conveyors enable.

Here are some key statistics:

• In 2018, around 25 million tons of yard trimmings and food waste were composted in the US, equal to 8.4% of the total MSW generated.
• Globally in 2021, the leading countries for organic waste recycling were South Korea at 95%, Germany at 56%, and Austria at 55%.
• The world generates around 3.5 billion tons of organic waste annually. With population growth, this is projected to rise to over 5 billion tons by 2050.
• In the US, yard trimmings composting has increased from 7 million tons in 1990 to over 22 million tons today. Food waste composting remains under 3 million tons.
• High composting rates are achieved for yard trimmings (61%) and food scraps (15%), but other organics like wood (2%) and paper (4%) lag far behind.
• Efficient collection and transport not only contribute to environmental sustainability but also present a significant business opportunity.

By leveraging high-quality conveyor systems, biomass recycling operations can reduce costs and maximize material recovery.
